ABB ACS150 series User Manual

89
Actual signals and parameters
Parameters in the Long parameter mode
Index
Name/Selection
Description
Def
0 = NOT SEL
Not selected
-1 = DI1(INV)
Inverted digital input DI1. 1 = jogging inactive, 0 = jogging active.
-2 = DI2(INV)
See selection DI1(INV).
-3 = DI3(INV)
See selection DI1(INV).
-4 = DI4(INV)
See selection DI1(INV).
-5 = DI5(INV)
See selection DI1(INV).
11 REFERENCE
SELECT
Panel reference type, local reference source, external control location
selection and external reference sources and limits
The drive can accept a variety of references in addition to the conventional
analog input, potentiometer and control panel signals:
- The drive reference can be given with two digital inputs: One digital input
increases the speed, the other decreases it.
- The drive can form a reference out of analog input and potentiometer
signals by using mathematical functions: Addition, subtraction.
- The drive reference can be given with a frequency input.
It is possible to scale the external reference so that the signal minimum and
maximum values correspond to a speed other than the minimum and
maximum speed limits.
1101 KEYPAD REF SEL
Selects the type of the reference in the local control mode.
1 = REF1
1 = REF1(Hz)
Frequency reference
2 = REF2(%)
%-reference
1102 EXT1/EXT2 SEL
Defines the source from which the drive reads the signal that selects
between two external control locations, EXT1 or EXT2.
0 = EXT1
0 = EXT1
EXT1 active. The control signal sources are defined by parameters 1001
EXT1 COMMANDS and 1103 REF1 SELECT.
1 = DI1
Digital input DI1. 0 = EXT1, 1 = EXT2.
2 = DI2
See selection DI1.
3 = DI3
See selection DI1.
4 = DI4
See selection DI1.
5 = DI5
See selection DI1.
7 = EXT2
EXT2 active. The control signal sources are defined by parameters 1002
EXT2 COMMANDS and 1106 REF2 SELECT.
-1 = DI1(INV)
Inverted digital input DI1. 1 = EXT1, 0 = EXT2.
-2 = DI2(INV)
See selection DI1(INV).
-3 = DI3(INV)
See selection DI1(INV).
-4 = DI4(INV)
See selection DI1(INV).
-5 = DI5(INV)
See selection DI1(INV).
1103 REF1 SELECT
Selects the signal source for external reference REF1.
1 = AI1
0 = KEYPAD
Control panel
1 = AI1
Analog input AI1
2 = POT
Potentiometer

ABB ACS150 series Specifications

General

Power Range	0.37 to 4 kW
Frequency Range	0 to 500 Hz
Protection Class	IP20
Overload Capacity	150% for 60 seconds
Braking Chopper	Built-in
Control Method	Scalar control
Supply Voltage	200-240 V (1-phase), 200-480 V (3-phase)
EMC Filter	Built-in
Input Voltage	200-240 V (1-phase), 200-480 V (3-phase)
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit
Communication Options	Modbus RTU
Voltage Range	200 to 240 V (1-phase), 380 to 480 V (3-phase)
