Parameters 223
Direct temperature The temperature is taken from the source selected by
parameter 35.24 Temperature 2 AI source. The value of
the source is assumed to be degrees Celsius.
11
35.22 Temperature 2 fault
limit
Defines the fault limit for temperature supervision
function 2. The unit is selected by parameter 96.16 Unit
selection.
Note: With a PTC sensor, the unit is ohms.
130 °C or
266 °F
-10…1000 °C or
14…1832 °F
Fault limit for temperature monitoring function 2. 1 = 1 unit
35.23 Temperature 2
warning limit
Defines the warning limit for temperature supervision
function 2. The unit is selected by parameter 96.16 Unit
selection.
Note: With a PTC sensor, the unit is ohms.
110 °C or
230 °F
-10…1000 °C or
14…1832 °F
Warning limit for temperature monitoring function 2. 1 = 1 unit
35.24 Temperature 2 AI
source
Selects the input for parameter 35.21 Temperature 2
source selections KTY84 analog I/O, 1 x Pt100 analog
I/O, 2 x Pt100 analog I/O, 3 x Pt100 analog I/O, Direct AI
temperature, KTY83 analog I/O, 1 x Pt1000 analog I/O, 2
x Pt1000 analog I/O, 3 x Pt1000 analog I/O and NI1000
Not selected
Not selected None. 0
AI1 actual value Analog input AI1 on the control unit. 1
AI2 actual value Analog input AI2 on the control unit. 2
Other Source selection (see Terms and abbreviations). -
35.50 Motor ambient
temperature
Defines the ambient temperature of the motor for the
motor thermal protection model. The unit is selected by
parameter 96.16 Unit selection.
The motor thermal protection model estimates the motor
temperature on the basis of parameters 35.50 … 35.55.
The motor temperature increases if it operates in the
region above the load curve, and decreases if it operates
in the region below the load curve.
WARNING! The model cannot protect the motor if
the motor does not cool properly because of dust,
dirt, etc.
20 °C or
68 °F
-60…100 °C or
-75 … 212 °F
Ambient temperature. 1 = 1°
No. Name/Value Description Default
FbEq 16
