Parameters 121
Ext run enable Inverted bit 5 of 06.18 Start inhibit status word (see
page 119).
2
Other [bit] Source selection (see Terms and abbreviations on
page 101).
-
06.32 MSW bit 13 sel Selects a binary source whose status is transmitted as
bit 13 of 06.11 Main status word.
FALSE
FALSE 0. 0
True 1. 1
Other [bit] Source selection (see Terms and abbreviations on
page 101).
-
06.33 MSW bit 14 sel Selects a binary source whose status is transmitted as bit
14 of 06.11 Main status word.
FALSE
FALSE 0. 0
True 1. 1
Other [bit] Source selection (see Terms and abbreviations on
page 101).
-
06.50 User status word 1 User-defined status word. This word shows the status of
the binary sources selected by parameters 06.60…06.75.
This parameter is read-only.
-
0000h…FFFFh User-defined status word. 1 = 1
06.60 User status word 1 bit
0 sel
Selects a binary source whose status is shown as bit 0 of
06.50 User status word 1.
FALSE
FALSE 0. 0
True 1. 1
Other [bit] Source selection (see Terms and abbreviations on
page 101).
-
06.61 User status word 1 bit
1 sel
Selects a binary source whose status is shown as bit 1 of
06.50 User status word 1.
Out of window
FALSE 0. 0
True 1. 1
Out of window Bit 3 of 06.19 Speed control status word (see page 120). 2
Other [bit] Source selection (see Terms and abbreviations on
page 101).
-
06.62 User status word 1 bit
2 sel
Selects a binary source whose status is shown as bit 2 of
06.50 User status word 1.
Emergency
stop failed
FALSE 0. 0
True 1. 1
Emergency stop
failed
Bit 8 of 06.17 Drive status word 2 (see page 118). 2
No. Name/Value Description Def/
FbEq16
Bit Name Description
0 User status bit 0 Status of source selected by parameter 06.60
1 User status bit 1 Status of source selected by parameter 06.61
…… …
15 User status bit 15 Status of source selected by parameter 06.75
