166 Parameters
Motor speed used 01.01 Motor speed used (page 105). 1
Output frequency 01.06 Output frequency (page 105). 3
Motor current 01.07 Motor current (page 105). 4
Motor torque 01.10 Motor torque (page 105). 6
DC voltage 01.11 DC voltage (page 105). 7
Power inu out 01.14 Output power (page 106). 8
Speed ref ramp in 23.01 Speed ref ramp input (page 203). 10
Speed ref ramp out 23.02 Speed ref ramp output (page 204). 11
Speed ref used 24.01 Used speed reference (page 210). 12
Torq ref used 26.02 Torque reference used 13
Freq ref used 28.02 Frequency ref ramp output (page 226). 14
Force PT100
excitation
The output is used to feed an excitation current to 1…3
Pt100 sensors. See section Motor thermal protection
(page 83).
20
Force KTY84
excitation
The output is used to feed an excitation current to a KTY84
sensor. See section Motor thermal protection (page 83).
21
Force PTC excitation The output is used to feed an excitation current to 1…3
PTC sensors. See section Motor thermal protection (page
83).
22
Force Pt1000
excitation
The output is used to feed an excitation current to 1…3
Pt1000 sensors. See section Motor thermal protection
(page 83).
23
AO1 data storage 13.91 AO1 data storage (page 149). 37
AO2 data storage 13.92 AO2 data storage (page 149). 38
Other Source selection (see Terms and abbreviations on page
101).
-
14.78 AO1 force data (Visible when 14.01 Module 1 type = FIO-11 or FAIO-01)
Forced value that can be used instead of the selected
output signal. See parameter 14.71 AO force selection.
0.000 mA
0.000…22.000 mA Forced value of analog output AO1. 1000 = 1 mA
No. Name/Value Description Def/
FbEq16
