Parameters 207
23.19 Shape time dec 2 Defines the shape of the deceleration ramp at the end of
the deceleration. See parameter 23.16 Shape time acc 1.
0.000 s
0.000…1800.000 s Ramp shape at end of deceleration. 10 = 1 s
23.20 Acc time jogging Defines the acceleration time for the jogging function i.e.
the time required for the speed to change from zero to the
speed value defined by parameter 46.01 Speed scaling.
60.000 s
0.000 …1800.000 s Acceleration time for jogging. 10 = 1 s
23.21 Dec time jogging Defines the deceleration time for the jogging function i.e.
the time required for the speed to change from the speed
value defined by parameter 46.01 Speed scaling to zero.
60.000 s
0.000 …1800.000 s Deceleration time for jogging. 10 = 1 s
23.23 Emergency stop time In speed control mode, this parameter defines the
deceleration rate for emergency stop Off3 as the time it
would take for the speed to decrease from the value of
parameter 46.01 Speed scaling to zero. This also applies
to torque control (if present) because the drive switches to
speed control on receiving an emergency stop Off3
command.
In frequency control mode, this parameter specifies the
time it would take for the frequency to decrease from the
value of 46.02 Frequency scaling to zero.
The emergency stop mode and activation source are
selected by parameters 21.04 Emergency stop mode and
21.05 Emergency stop source respectively. Emergency
stop can also be activated through fieldbus.
Note: Emergency stop Off1 uses the standard
deceleration ramp as defined by parameters 23.11…23.19
(speed control) or 28.71…28.75 (frequency control).
3.000 s
0.000…1800.000 s Emergency stop Off3 deceleration time. 10 = 1 s
23.24 Speed ramp in zero
source
Selects a source that forces the speed reference to zero
just before it enters the ramp function.
0 = Force speed reference to zero before the ramp
function
1 = Speed reference continues towards the ramp function
as normal
Inactive
Active 0. 0
Inactive 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (
10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11 .02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11 .02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on
page 101).
-
No. Name/Value Description Def/
FbEq16
