236 Parameters
30.02 Torque limit status Displays the torque controller limitation status word.
This parameter is read-only.
-
0000h…FFFFh Torque limitation status word. 1 = 1
30.11 Minimum speed Defines the minimum allowed speed.
WARNING!
This value must not be higher than 30.12 Maximum
speed.
In frequency control mode, this limit is not effective.
Make sure the frequency limits (30.13 and 30.14)
are set appropriately if frequency control is used.
-1500.00 rpm;
-1800.00 rpm
(95.20 b0)
-30000.00
…30000.00 rpm
Minimum allowed speed. See par.
46.01
30.12 Maximum speed Defines the maximum allowed speed.
WARNING! This value must not be lower than
30.11 Minimum speed.
WARNING! In frequency control mode, this limit is
not effective. Make sure the frequency limits (30.13
and 30.14) are set appropriately if frequency
control is used.
1500.00 rpm;
1800.00 rpm
(95.20 b0)
-30000.00
…30000.00 rpm
Maximum speed. See par.
46.01
No. Name/Value Description Def/
FbEq16
Bit Name Description
0 Undervoltage *1 = Intermediate DC circuit undervoltage
1 Overvoltage *1 = Intermediate DC circuit overvoltage
2 Minimum torque *1 = Torque is being limited by 30.19 Minimum torque 1, 30.26
Power motoring limit or 30.27 Power generating limit
3 Maximum torque *1 = Torque is being limited by 30.20 Maximum torque 1, 30.26
Power motoring limit or 30.27 Power generating limit
4 Internal current 1 = An inverter current limit (identified by bits 8…11) is active
5 Load angle (With permanent magnet motors and synchronous reluctance
motors only)
1 = Load angle limit is active, ie. the motor cannot produce any
more torque
6 Motor pullout (With asynchronous motors only)
1 = Motor pull-out limit is active, ie. the motor cannot produce
any more torque
7 Reserved
8 Thermal 1 = Input current is being limited by the main circuit thermal limit
9 Max current *1 = Maximum output current (I
MAX
) is being limited
10 User current *1 = Output current is being limited by 30.17 Maximum current
11 Thermal IGBT *1 = Output current is being limited by a calculated thermal
current value
12 IGBT overtemperature *1 = Output current is being limited because of estimated IGBT
temperature
13 IGBT overload *1 = Output current is being limited because of IGBT junction to
case temperature
14…15 Reserved
*Only one out of bits 0…3, and one out of bits 9…13 can be on simultaneously. The bit typically
indicates the limit that is exceeded first.

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
