ABB ACS880 PCP User Manual

Parameters 305
Constant ref Constant speed reference. See par. 74.06.6
Other Source selection (see Terms and abbreviations on 101). -
74.06 Speed ref Sets the speed reference for parameter 74.05 Speed ref
source, if set as Constant ref.
0.00 Prpm,
rpm or Hz
0.00...30000.00 Prpm Speed reference. 10 = 1 Prpm,
rpm or Hz
74.07 Minimum rod speed Defines the minimum allowed rod/pump speed.
WARNING! This value must not be higher than
74.06 Speed ref
Note: Operational units for PCP is Prpm and for ESP is
Hz.
0.00 Prpm,
rpm or Hz
-10000.00
...10000.00 Prpm
Minimum rod speed. 10 = 1 Prpm,
rpm or Hz
74.08 Maximum rod speed Defines the maximum allowed rod/pump speed.
WARNING! This value must not be lower than
74.07 Minimum rod speed.
Note: Operational unit for PCP and ESP is rpm and Hz
respectively.
0.00 Prpm,
rpm or Hz
-10000.00
...10000.00 Prpm
Maximum rod speed. 10 = 1 Prpm,
rpm or Hz
74.10 Rod acc time Defines the acceleration time for the rod/pump: from zero
to 74.08 Maximum rod speed.
20.000 s
0.000...10000.000 s Rod acceleration time. 10 = 1 s
74.11 Rod dec time Defines the deceleration time for the rod/pump: from 74.08
Maximum rod speed to zero speed.
20.000 s
0.000...10000.000 s Rod acceleration time. 10 = 1 s
74.12 Starting speed enable Enables the pump starting speed function. See section
Pump starting speed on page 33.
Disable
Disable Disables pump ramp up. 0
Enable Enables pump ramp up. 1
Other Source selection (see Terms and abbreviations on
page 101).
-
74.13 Starting speed Defines the starting speed. See section Pump starting
speed on page 33.
0.00 Prpm,
rpm or Hz
-10000.00...
10000.00 Prpm
Pump starting speed. 10 = 1 Prpm,
rpm or Hz
74.14 Starting speed acc
time
Defines the acceleration time for the Pump starting speed
function. See section Pump starting speed on page 33.
0.000 s
0.0000
...10000.000 s
Pump starting speed acceleration time. 10 = 1 s
74.15 Starting speed time
delay
Defines the delay time for the Pump starting speed
function. After this delay, start up procedure ends and the
function releases control over speed reference.
0.000 s
0.0000
...10000.000 s
Starting speed delay time. 10 = 1 s
No. Name/Value Description Def/
FbEq16

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
