304 Parameters
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 8
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 9
Other Source selection (see Terms and abbreviations on
page 101).
-
74.02 Run-time hours reset
source
Defines the command source used to reset the run-time
hour counter (09.07 Run-time hours) of the pump.
No
No Run-time hours reset disabled. 0
Yes Run-time hours reset enabled. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 8
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 9
Other Source selection (see Terms and abbreviations
on 101). -
74.03 Gear reduction ratio Defines the transmission reduction ratio for PCP
application.
Note: This feature is not available for ESP.
1.000
1.000...1000.000 Value range. 1000 = 1
74.04 Speed ref type Selects the reference type between motor speed or pump
speed.
Note: Not applicable for ESP.
Pump speed
Pump speed Speed reference of the pump. 0
Motor speed Speed reference of the motor. 1
74.05 Speed ref source Selects the source for the speed reference. AI1 scaled
Zero Source not selected. 0
AI1 scaled 12.12 AI1 scaled value (see page 141). 1
AI2 scaled 12.22 AI2 scaled value (see page 141). 2
FBA1 ref Fieldbus adapter A reference1. 3
FBA2 ref Fieldbus adapter A reference2. 4
EFB1 ref Embedded fieldbus reference 1.
EFB2 ref Embedded fieldbus reference 2.
Motor potentiometer
ref
22.80 Motor potentiometer ref act (output of the motor
potentiometer)
5
No. Name/Value Description Def/
FbEq16
