3.3.3 Inspecting the oil level in axis-3 gearbox
Location of gearbox
The axis 3 gearbox is located in the upper arm rotational center as shown in the
figure.
xx0600002961
Oil plug, fillingA
Oil plug, inspectionB
Oil plug, drainingC
Required equipment
NoteArt. no.Equipment, etc.
Note! Do not mix with other oils!See Type and amount
of oil in gearboxes on
page 149.
Lubricating oil
Content is defined in section
Standard tools on page 346.
-Standard toolkit
These procedures include refer-
ences to the tools required.
Other tools and procedures may
be required. See references to
these procedures in the step-by-
step instructions below.
