2.4 Unpacking
2.4.1 Pre-installation procedure
Introduction
This section is intended for use when unpacking and installing the robot for the
first time. It also contains information useful during later re-installation of the robot.
Prerequisites for installation personnel
Installation personnel working with an ABB product must:
• be trained by ABB and have the required knowledge of mechanical and
electrical installation/maintenance/repair work
• conform to all national and local codes.
Checking the pre-requisites for installation
Action
Make a visual inspection of the packaging and make sure that nothing is damaged.1
Remove the packaging.2
Check for any visible transport damage.
Note
Stop unpacking and contact ABB if transport damages are found.
3
Clean the unit with a lint-free cloth, if necessary.4
Make sure that the lifting accessory used (if required) is suitable to handle the weight
of the robot as specified in: Weight, robot on page 58
5
If the robot is not installed directly, it must be stored as described in: Storage condi-
tions, robot on page 60
6
Make sure that the expected operating environment of the robot conforms to the
specifications as described in: Operating conditions, robot on page 60
7
Before taking the robot to its installation site, make sure that the site conforms to:
• Loads on foundation, robot on page 58
• Protection classes, robot on page 60
• Requirements, foundation on page 59
8
Before moving the robot, please observe the stability of the robot: Risk of tipping/sta-
bility on page 65
9
When these prerequisites are met, the robot can be taken to its installation site as
described in section: On-site installation on page 66
10
Install required equipment, if any.
• Signal lamp (option) on page 105
11
Continues on next page
Product manual - IRB 6620 57
3HAC027151-001 Revision: T
© Copyright 2006-2018 ABB. All rights reserved.
