3.3.10 Inspecting the additional mechanical stops
Location of mechanical stops
The figure shows the location of the additional mechanical stops on axes 1 and 3.
Additional mechanical stops are not provided for axis 2.
xx0600002938
Additional stop, axis 1A
Attachment screws and washers (2 pcs)B
Fixed stopC
Mechanical stop pin, axis 1D
Continues on next page
Product manual - IRB 6620 141
3HAC027151-001 Revision: T
© Copyright 2006-2018 ABB. All rights reserved.
3 Maintenance
3.3.10 Inspecting the additional mechanical stops
