ACUTRONIC fabian HFO User Manual

136 Accessories and options
fabian HFO | SW 5.1.x
Ref: 113003.EN / Date 2020-02-10
12.6.6 FOT post data analysis
The exported system log files can be used for post data analysis. The log files contain the FOT
settings and the measurement results (Xrs and Resistance) at each pressure level.
12.6.7 FOT specifications
Fixed parameters
Amplitude (∆P) of forced
oscillation
5 mbar
FOT period
maximum 18 seconds (if the conditions are good, it is shorter)
3 seconds out of it is the FOT measurement/data collection time
Frequency of forced
oscillation
10 Hz
I:E ratio of forced
oscillation
1:1
Stabilization time
maximum 180 seconds (can be skipped)
Adjustable parameters
FOTsteps
1 to 21 (only odd numbers) *
Pmean low
5 to 49 mbar
Pmean high
6 to 50 mbar **
PEEPlow
3 to 29 mbar
1
2
3
4
5
6
7
