ACUTRONIC fabian HFO User Manual

System operation 49
fabian HFO | SW 5.1.x
Ref: 113003.EN / Date 2020-02-10
5.2.3 Connect nCPAP tubing
Preparing the nCPAP tubing system:
• Connect nCPAP adapter to the fabian
nCPAP port. (REF: 153001).
• Connect the 22 mm adapter connector
to the humidifier chamber inlet.
• Connect the nCPAP system pressure
measuring limb to the fabian port
marked (Prox).
• Connect the nCPAP system to
humidifier chamber.
• Apply the nCPAP system to the patient
according to its manufacturer
instructions.
For details of using nCPAP systems, refer to the manufacturer operator’s manual for consumables.
5.2.4 Triggering in DUOPAP mode with flow sensor (optional)
Preparing the nCPAP
InfantFlow/InfantFlowLP/Inspire Tubing
System
• Connect Flow sensor
to exhalation tube as
shown in the picture.
Recommendation:
• Make the Exhalation
tube as short as
possible.
