ACUTRONIC fabian HFO User Manual

System overview 19
fabian HFO | SW 5.1.x
Ref: 113003.EN / Date 2020-02-10
#
Description
1.
Connector for 24V DC external power supply (does not charge internal battery!)
2.
Network jack for data management, PDMS
(for conection to network with minimum 3KV galvanic isolation) (disabled)
3.
USB port for data output, software update and connection for Masimo SpO
2
module
4.
DB9 RS-232 port for etCO
2
option and PDMS
5.
Flow Sensor 7-pin Connector
6.
Nurse Call Connector
7.
Loudspeaker (Audio)
8.
Fan
9.
Optional ports
10.
Power connector (Fuse 1 AT)
11.
Equipotential connection
12.
O
2
Supply Connector 2.0 to 6.5 bar / max 40 l/min
13.
Pressurized Air Connector 2.0 to 6.5 bar / max 40 l/min
3.3.6 General hardware characteristics
WARNING
• DO NOT connect Ethernet, Nurse call, USB, RS-232 (etCO
2
), SpO
2
, Flow Sensor port
to anything other than specified devices.
• DO NOT connect anything to ethernet, Nurse call, and RS232, while operating on
battery power.
• ONLY connect IEC 60601-1 or IEC 60950-1 compliant devices to Ethernet, Nurse call,
and RS232 ports.
For Adapter to DISS see Accessories.
The pin for the Potential Equalization provide additional safety and can be connected to an
equipotential zone. Please adhere to local guidelines when using this pin. The guidelines may vary
between countries, localities and power companies. Always keep the pin for equipotential connection
accessible
Maximum Connected Loads:
Nurse call: Isolated relay output
Max contact load: 30 VDC @ 1A
USB: 5V @ 150 mA max
RS-232: Signal Levels: EIA/TIA-232 Standard
Pin 9 Power: 5V @ 500 mA max (models without DC input)
Isolated
