Additional Information on Arbitrary Waveforms
Press the Arb key to output the arbitrary waveform currently
selected (to scroll through the waveform choices and make a
selection, press
Arb List ).
In addition to creating a new arbitrary waveform from the front
panel, you can also edit any existing user-defined waveforms. You can
edit waveforms created either from the front panel or from the
remote interface. However, you cannot edit any of the five built-in
arbitrary waveforms.
Use the “
GET” option under the NEW ARB command in the EDIT MENU
to load an existing user-defined waveform. Then, use the LINE EDIT,
POINT EDIT, and INVERT commands to edit the waveform.
The INVERT command in the EDIT MENU takes the inverse of each
point in the specified waveform by changing the sign.
You can use the DELETE command in the EDIT MENU to delete any
user-defined waveforms in volatile memory. A list of all user-defined
waveforms appears when you move to the
DELETE command.
Chapter 3 Features and Functions
Arbitrary Waveforms
108
