To set the baud rate
You can select one of six baud rates for RS-232 operation. The rate is set
to
9600 baud when the function generator is shipped from the factory.
See also “Baud Rate Selection,” on page 116.
1 Turn on the menu.
A: MOD MENU
2 Move across to the
I/O MENU choice on this level.
E: I/O MENU
3 Move down a level and then across to the
BAUD RATE choice.
3: BAUD RATE
4 Move down to the “
PARAMETER” level to select the baud rate.
Use the left/right arrow keys to see the baud rate choices. Choose from
one of the following: 300, 600, 1200, 2400, 4800, or
9600 baud.
9600 BAUD
5 Save the change and exit the menu.
The baud rate selection is stored in non-volatile memory, and does not
change when power has been off or after a remote interface reset.
¿
¿
Enter
>
>
Menu On/Off
Shift
<
<
4
Chapter 4 Remote Interface Reference
To set the baud rate
219
