Tutorial
The Agilent 33120A is capable of producing a variety of signal
waveshapes. In order to achieve the greatest performance from the
function generator, it may be helpful if you learn more about the internal
operations of the instrument. This chapter describes basic signal
generation concepts and gives specific details on the internal operations
of the function generator.
Direct Digital Synthesis, starting on page 273
Signal Imperfections, starting on page 276
Creating Arbitrary Waveforms, starting on page 278
Output Amplitude Control, starting on page 280
Floating Signal Generators, on page 282
Attributes of AC Signals, starting on page 283
Modulation, starting on page 287
You can use an arbitrary waveform generator in a variety of
applications where it might be otherwise difficult or impossible to
generate complex output waveforms. With an arbitrary waveform
generator, signal imperfections such as rise time, ringing, glitches,
noise, and random timing variations can be easily simulated in a
controlled manner.
Physics, chemistry, biomedicine, electronics, mechanics, and other fields
can benefit from the versatility of an arbitrary waveform generator.
Wherever things vibrate, pump, pulse, bubble, burst, or change with
time in any way, there are possible applications — limited only by your
ability to provide waveform data.
The Agilent IntuiLink Arb Waveform Generation Software for
Microsoft
®
Windows
®
is designed to make it easy to create
and output arbitrary waveforms for the 33120A.
