To select the remote interface
The function generator is shipped with both an GPIB (IEEE-488)
interface and an
RS-232 interface. Only one interface can be enabled at
a time. The
GPIB interface is selected when the function generator is
shipped from the factory. See also “Remote Interface Selection,” on page 115.
1 Turn on the menu.
A: MOD MENU
2 Move across to the
I/O MENU choice on this level.
E: I/O MENU
3 Move down a level and then across to the
INTERFACE choice.
2: INTERFACE
4 Move down to the “
PARAMETER” level to select the interface.
Use the left/right arrow keys to see the interface choices. Choose from
the following:
HPIB / 488 or RS-232.
HPIB / 488
5 Save the change and turn off the menu.
The interface selection is stored in non-volatile memory, and does not
change when power has been off or after a remote interface reset.
¿
¿
Enter
>
Menu On/Off
Shift
<
<
Chapter 4 Remote Interface Reference
To select the remote interface
218
