Front-panel menu reference
B: SWP (Sweep) MENU
1: START F Õ 2: STOP F Õ 3: SWP TIME Õ 4: SWP MODE
1: AM SHAPE
2: AM SOURCE
3: FM SHAPE
4: BURST CNT
5: BURST RATE
6: BURST PHAS
7: BURST SRC
8: FSK FREQ
9: FSK RATE
10: FSK SRC
Selects the shape of the AM modulating waveform.
Enables or disables the internal AM modulating source.
Selects the shape of the FM modulating waveform.
Sets the number of cycles per burst (1 to 50,000 cycles).
Sets the burst rate in Hz for an internal burst source.
Sets the starting phase angle of a burst (-360 to +360 degrees).
Selects an internal or external gate source for burst modulation.
Sets the FSK “hop” frequency.
Selects the internal FSK rate between the carrier and FSK frequency.
Selects an internal or external source for the FSK rate.
1: START F
2: STOP F
3: SWP TIME
4: SWP MODE
Sets the start frequency in Hz for sweeping.
Sets the stop frequency in Hz for sweeping.
Sets the repetition rate in seconds for sweeping.
Selects linear or logarithmic sweeping.
1: NEW ARB
2: POINTS
3: LINE EDIT
4: POINT EDIT
5: INVERT
6: SAVE AS
7: DELETE
Initiates a new arb waveform or loads the selected arb waveform.
Sets the number of points in a new arb waveform (8 to 16,000 points).
Performs a linear interpolation between two points in the arb waveform.
Edits the individual points of the selected arb waveform.
Inverts the selected arb waveform by changing the sign of each point.
Saves the current arb waveform in non-volatile memory.
Deletes the selected arb waveform from non-volatile memory.
*
The commands enclosed in square brackets ( [ ] ) are “hidden” until you make a selection from the NEW ARB command
to initiate a new edit session.
C: EDIT MENU
*
1: NEW ARB Õ [ 2: POINTS ] Õ [ 3: LINE EDIT ] Õ [ 4: POINT EDIT ] Õ [ 5: INVERT ] Õ [ 6: SAVE AS ] Õ 7: DELETE
A: MODulation MENU
1: AM SHAPE Õ 2: AM SOURCE Õ 3: FM SHAPE Õ 4: BURST CNT Õ 5: BURST RATE Õ
Õ 6: BURST PHAS Õ 7: BURST SRC Õ 8: FSK FREQ Õ 9: FSK RATE Õ 10: FSK SRC
2
Chapter 2 Front-Panel Menu Operation
Front-panel menu reference
31
