Carrier Waveform Shape
 AM carrier shape: Sine, Square, Triangle, Ramp, or Arbitrary
waveform. The default is Sine.
 You cannot use the noise function or dc volts as the carrier waveform.
 Front-Panel Operation: Press any of the front-panel function keys
except
Noise . For arbitrary waveforms, the Arb key selects the
waveform that is currently downloaded.
 Remote Interface Operation:
FUNCtion:SHAPe {SINusoid|SQUare|TRIangle|RAMP|USER}
You can also use the APPLy command to select the function,
frequency, amplitude, and offset with a single command.
Carrier Frequency
 Carrier frequency: 100 mHz to 15 MHz (100 kHz for triangle and
ramp). The default is 1 kHz.
 For arbitrary waveforms, the maximum carrier frequency depends on
the number of points specified in the waveform. The five built-in
arbitrary waveforms can be output at a maximum of 5 MHz.
 Front-Panel Operation: Press the Freq key to select any valid
frequency for the selected function (the present amplitude and offset
voltage are used).
 Remote Interface Operation:
FREQuency {<
frequency>|MINimum|MAXimum}
Number of Arb Points
8 to 8,192 (8k)
8,193 to 12,287 (12k)
12,288 to 16,000
Minimum Frequency
100
m Hz
100
m Hz
100
m Hz
Maximum Frequency
5 MHz
2.5 MHz
200 kHz
Chapter 3 Features and Functions
Amplitude Modulation (AM)
72
