Agilent Technologies 33120A User Manual

WAVEFORMS
Standard Waveforms:
Arbitrary Waveforms:
Waveform Length:
Amplitude Resolution:
Sample Rate:
Non-Volatile Memory:
Sine, Square, Triangle,
Ramp, Noise, DC volts,
Sine(x)/x, Negative Ramp,
Exponential Rise,
Exponential Fall, Cardiac
8 to 16,000 points
12 bits (including sign)
40 MSa / sec
Four 16,000-point waveforms
FREQUENCY CHARACTERISTICS
Sine:
Square:
Triangle:
Ramp:
Noise (Gaussian):
Arbitrary Waveforms:
8 to 8,192 points:
8,193 to 12,287 points:
12,288 to 16,000 points:
Resolution:
Accuracy:
Temperature Coefficient:
Aging:
100
m Hz – 15 MHz
100
m Hz – 15 MHz
100
m Hz – 100 kHz
100
m Hz – 100 kHz
10 MHz bandwidth
100
m Hz – 5 MHz
100
m Hz – 2.5 MHz
100
m Hz – 200 kHz
10
m Hz or 10 digits
10 ppm in 90 days,
20 ppm in 1 year,
18
 C – 28  C
< 2 ppm /
 C
< 10 ppm / yr
SINEWAVE SPECTRAL PURITY (into 50 W )
Harmonic Distortion
DC to 20 kHz:
20 kHz to 100 kHz:
100 kHz to 1 MHz:
1 MHz to 15 MHz:
Total Harmonic Distortion
DC to 20 kHz:
Spurious (non-harmonic)
Output (DC to 1 MHz):
Output (> 1 MHz):
Phase Noise:
-70 dBc
-60 dBc
-45 dBc
-35 dBc
< 0.04%
< -65 dBc
< -65 dBc + 6 dB/octave
< -55 dBc in a 30 kHz band
SIGNAL CHARACTERISTICS
Square wave
Rise/Fall Time:
Overshoot:
Asymmetry:
Duty Cycle:
Triangle, Ramp, Arb
Rise/Fall Time:
Linearity:
Settling Time:
Jitter:
< 20 ns
< 4%
1% + 5 ns
20% to 80% (to 5 MHz)
40% to 60% (to 15 MHz)
40 ns (typical)
< 0.1% of peak output
< 250 ns to 0.5% of final value
< 25 ns
OUTPUT CHARACTERISTICS
(1)
Amplitude (into 50
W ): (2)
Accuracy (at 1 kHz):
Flatness
< 100 kHz:
100 kHz to 1 MHz:
1 MHz to 15 MHz:
1 MHz to 15 MHz:
Offset (into 50
W ):
(3)
Accuracy:
(4)
Output Impedance:
Resolution:
Output Units:
Isolation:
Protection:
50 mVpp – 10 Vpp
 1% of specified output
(sine wave relative to 1 kHz)
 1% (0.1 dB)
 1.5% (0.15 dB)
 2% (0.2 dB) Ampl  3Vrms
 3.5% (0.3 dB) Ampl < 3Vrms
 5 Vpk ac + dc
 2% of setting + 2 mV
50 ohms fixed
3 digits, Amplitude and Offset
Vpp, Vrms, dBm
42 Vpk maximum to earth
Short-circuit protected
 15 Vpk overdrive < 1 minute
(1) Add 1/10th of output amplitude and offset specification
per
 C for operation outside of 18  C to 28  C range
(1-year specification).
(2) 100 mVpp – 20 Vpp amplitude into open-circuit load.
(3) Offset
 2 X peak-to-peak amplitude.
(4) For square wave outputs, add 2% of output amplitude
additional error.
Chapter 8 Specifications
Agilent 33120A Function Generator
298
