F
factory setting
baud rate (RS-232), 116, 219
calibration security code, 118
data bits (RS-232), 116, 220
GPIB address, 114, 217
parity (RS-232), 116, 220
firmware revision, 113, 190
floating-point data, 178
FM annunciator, 5
FM modulation
carrier frequency, 78
carrier waveshape, 77
modulating frequency, 79, 159
modulating waveshape, 79, 159
operational overview, 157
peak frequency deviation, 80, 158
sync signal, 79
technical description, 288
FM:DEV command, 158
FM:INT:FREQ command, 159
FM:INT:FUNC command, 159
FM:STAT command, 159
FORM:BORD command, 185
FREQ command, 146
FREQ:STAR command, 171
FREQ:STOP command, 171
frequency deviation (FM), 80, 158
frequency sweep
See sweep
frequency
arb waveform limits, 57, 146
conflict with duty cycle, 58, 147
conflict with function, 58, 146
front-panel selection, 19
limits, 57, 146
modulation, 76, 157
remote interface selection, 57, 146
frequency-shift keying
See FSK
front panel
annunciators, 5
dc volts selection, 24
downloading waveforms, 103 - 108
menu examples, 33 - 39
menu messages, 34
menu reference, 31 - 32
number entry, 3, 38
overview, 2
front-panel display
annunciators, 5
enable/disable, 112, 188
text message, 112, 188
FSK annunciator, 5
FSK terminal, 102
FSK
carrier frequency, 91
front-panel operation, 44
“hop” frequency, 92, 168
internal rate, 93, 168
maximum external rate, 93
operational overview, 167
source, 93, 169
sync signal, 91
technical description, 290
FSK:FREQ command, 168
FSK:INT:RATE command, 168
FSK:SOUR command, 169
FSK:STAT command, 169
FUNC:SHAP command, 145
FUNC:SHAP USER command, 177
FUNC:USER command, 176
function
conflict with amplitude, 55
conflict with frequency, 55
front-panel selection, 56
modulation matrix, 56, 145
remote interface selection, 145
fuse, power line, 16
G
gate source
burst modulation, 164
gated burst mode, 81, 160
GPIB
arb waveform download, 255
capability codes, 225
download speeds, 299
selecting interface, 115, 218
GPIB address
factory setting, 114, 217
selecting, 114, 217
GPIB Command Library, 244
ground loops, 282
ground, chassis, 6
Group Execute Trigger, 101, 186
H
handle
adjustment, 18
changing positions, 18
removing, 27
handshake (RS-232), 198
haversine, example, 248
heartbeat waveform, 175
hop frequency (FSK), 92, 168
HP-IB address
See GPIB address
I
identification string, 113, 190
IEEE-488
common commands, 214, 225
conformance information, 225
selecting interface, 115, 218
IEEE-488 address
factory setting, 114, 217
selecting, 114, 217
inherent offset, 63, 177
interface address
factory setting, 114, 217
selecting, 114, 217
IntuiLink software, 1
