Agilent Technologies 33120A User Manual

Output Function
(continued)
 The following matrix shows which output functions are allowed with
each modulation mode. Each “
X” indicates a valid combination. If you
change to a function that is not allowed with the selected modulation,
the modulation mode is turned off.
 Front-Panel Operation: To select a function, press any key in the top
row of function keys. Press
Arb to output the arbitrary waveform
currently selected (to scroll through the waveform choices and
make a selection, press
Arb List ).
 To select dc volts from the front panel, press Offset and hold it down
for more than 2 seconds
.
 Remote Interface Operation:
FUNCtion:SHAPe {SINusoid|SQUare|TRIangle|RAMP|NOISe|USER|DC}
You can also use the APPLy command to select the function,
frequency, amplitude, and offset with a single command.
AM Carrier
AM Modulating Wave
FM Carrier
FM Modulating Wave
FSK Modulation
Burst Modulation
Frequency Sweep
Sine
X
X
X
X
X
X
X
Square
X
X
X
X
X
X
X
Triangle
X
X
X
X
X
X
X
Ramp
X
X
X
X
X
X
X
Noise
X
X
Arb
X
X
X
X
X
X
X
Chapter 3 Features and Functions
Output Configuration
56
