Publication 1734-UM014A-EN-P - November 2010
Install Your Adapter 13
Install the POINT I/O
Adapter Module
To install the adapter on the DIN rail prior to installing other base units:
1. Position the adapter vertically above the DIN rail.
2. Press down firmly to install the adapter on the DIN rail, noting that a
locking mechanisme locks the adapter to the DIN rail.
3. Set the node address on the node address thumbwheel.
4. Slide the safety end cap up to remove it, exposing the backplane and
power interconnections
.
Install the ArmorPOINT I/O
Adapter Module
To install the ArmorPOINT I/O adapter:
1. Using a bladed screwdriver, rotate the keyswitch on the mounting base
clockwise until the appropriate number for the I/O module you are
installing aligns with the notch in the base.
Refer to the installation instructions for each module to determine what
this number must be. See Where to Find More Information on page i
for a list of these installation instructions.
2. Position the module vertically above the mounting base.
The module bridges two bases.
3. Push the module down until it engages the latching mechanism.
You hear a clicking sound when the module is properly engaged. The
locking mechanism locks the module to the base.
Allow 25.4 mm (1 in.) of space between adjacent equipment for
adequate ventilation.
Do not discard the end cap. Use this end cap to cover the exposed
interconnections on the last mounting base on the DIN rail. Failure to
do so could result in equipment damage or injury from electric shock.
