Allen-Bradley POINT I/O User Manual

75 Publication 1734-UM014A-EN-P - November 2010
Appendix A
EtherNet/IP I/O Adapter Specifications
Specifications
Following are specifications for the ArmorPOINT I/O and POINT I/O
modules
General Specifications – POINT I/O and ArmorPOINT I/O 2 Port EtherNet/IP
Adapters 1734-AENTR, 1738-AENTR
Specification Description
Module location Starter module - left side of the 1734 system
LED Indicators Adapter status - green/red
Network status - green/red
POINTBus status - green/red
Network activity - green
System power (POINTBus 5V power) - green
Field power (24V from field supply) - green
Link activity status - green/yellow
Input voltage ratings,
nom
24V DC
Input voltage range 10…28.8V DC
Inrush current, max 6 A for 10 ms
Power consumption, max 10.4 W @ 28.8V DC
Power dissipation, max 6.3 W @ 28.8V DC
Thermal dissipation, max 21.5 BTU/hr. @ 28.8V DC
POINTBus output current,
max
0.8 A @ 5V DC ± 5% (4.75…5.25)
Input overvoltage
protection
Reverse polarity protected
Isolation voltage 50V (continuous), Basic Insulation Type
Tested at 1250V rms for 60s
Field side power, max 24V DC (+ 20% = 28.8V DC) @ 400 mA
Fieldbus power current,
max
10 A
Fieldbus power range 10…28.8V DC
Interruption Output voltage will stay within specifications when input
drops out for 10 ms at 10V with maximum load
Wiring category
(1)
(1)
Use this conductor category information for planning conductor routing. Refer to publication 1770-4.1, Industrial
Automation Wiring and Grounding Guidelines.
1 – on power ports
2 – on communications ports
