49 Publication 1734-UM014A-EN-P - November 2010
Chapter
5
Configure the Adapter for Direct Connection
and Rack Optimization in RSLogix 5000
Software
Overview
This chapter guides you through the steps required to configure your AENTR
adapter with both direct and rack-optimized I/O connections using
RSLogix 5000 software.
You can mix I/O connection formats for different I/O modules
communicating through the same adapter. I/O modules set up to use rack
optimization communicate at the rate of the RPI configured for the adapter.
I/O modules controlled by a direct I/O connection communicate at their own
set RPI. The RPI of the rack-optimized I/O connection has no bearing on the
direct I/O connections. The modules presented in this chapter have a
configuration using RSLogix 5000 software, revision 11. The chapter contains
the following main sections
.
Topic Page
Set Up the Hardware 50
Create the Example Application 51
Configure the I/O Modules 52
Add the Local EtherNet/IP Bridge to the I/O Configuration 52
Add the I/O Adapter to the I/O Configuration 54
Add the POINT I/O Module and Configure for Rack-optimized
Connection
58
Add the POINT I/O Module and Configure For Direct Connection 60
Download the Program to the Controller 62
Verify the Module Chassis Size 64
Access Module Data 66
You must use series C POINT I/O modules with the adapter.
Series A or B POINT I/O modules will not work with the
adapter.
