27 Publication 1734-UM014A-EN-P - November 2010
Chapter
4
Configure the Adapter for Direct Connection
in RSLogix 5000 Software
Overview
In this example, a ControlLogix controller communicates with I/O modules
via the adapter using a direct connection.
The adapter makes a direct connection to each of the modules referenced by
the data. The modules presented in this chapter use RSLogix 5000 software,
revision 11.
Set Up the Hardware
In this example, a ControlLogix chassis contains the L63 controller in slot 1
and a 1756-ENBT bridge module in slot 3. The 1734-AENTR adapter is
mounted on a DIN rail in slot 0, with a 1734-OW2/C relay output module in
slot 1, a 1734-OV4E/C sink output module in slot 2, and a power supply (not
shown).
You must use series C POINT I/O modules with the adapter.
Series A or B POINT I/O modules will not work with adapter.
Topic Page
Set Up the Hardware 27
Create the Example Application 29
Configure the I/O 30
Add the Local EtherNet/IP Bridge to the I/O Configuration 30
Add the POINT I/O Adapter to the I/O Configuration 33
Add the POINT I/O Modules to the I/O Configuration 36
Edit the Controller Tags 40
Create the Ladder Program 42
Download the Program to the Controller 42
Verify the Module Chassis Size 43
Configure the Adapter with Fixed IP Address 45
Recover From an Overloaded Adapter 46
