Rockwell Automation Publication 750-PM001N-EN-P - February 2017 13
Chapter 1
Startup
This chapter provides the information that is required to start up the PowerFlex®
750-Series drive.
Start-Up Check List
• This check list supports the Start-Up menu option.
• A Human Interface Module (HIM) is required to run the Start-Up
routine.
For detailed information on by using the HIM, refer to the Enhanced
PowerFlex 7-Class Human Interface Module (HIM) User Manual,
publication 20HIM-UM001
.
• The Start-Up routine can modify parameter values for Analog and Digital
I/O.
Prepare For Initial Drive Startup
❏ 1. Confirm that drive has been installed according to the PowerFlex 750-
Series AC Drives Installation Instructions, publication 750-IN001
.
❏ 2. Confirm that all inputs are connected to the correct terminals and are
secure.
❏ 3. Verify that AC line power at the disconnect device is within the rated value
of the drive.
❏ 4. Verify that control power voltage is correct.
Topic Page
Start-Up Check List 13
Start-Up Menu 15
Drive Status Indicators 16
Establishing A Connection With EtherNet/IP 17
ATTENTION: Power must be applied to the drive to perform the following start-up
procedure. Some of the voltages present are at incoming line potential. To avoid electric
shock hazard or damage to equipment, it is recommended that only qualified service
personnel perform the following procedure. Thoroughly read and understand the
procedure before beginning.
To Next Page
