Chapter 4 Port 10 and Port 11 Parameters
Converter n (Port 11)
Parameters
Converter n parameters apply only to PowerFlex 755 AC Input Frame 8 and
larger drives.
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
CONVERTER N
Status
105
205
305
C1 Fault Status1
C2 Fault Status1
C3 Fault Status1
Converter n Fault Status 1
RO 32-bit
Integer
Indicates which fault conditions currently exist for converter n. Refer to Chapter
6 - Converter (Port 11) Faults and Alarms (Frame 8 and Larger) for information on
these fault codes.
106
206
306
C1 Fault Status2
C2 Fault Status2
C3 Fault Status2
Converter n Fault Status 2
RO 32-bit
Integer
Indicates which fault conditions currently exist for converter n. Refer to Chapter
6 - Converter (Port 11) Faults and Alarms (Frame 8 and Larger) for information on
these fault codes.
107
207
307
C1 Alarm Status1
C2 Alarm Status1
C3 Alarm Status1
Converter n Alarm Status 1
RO 32-bit
Integer
Indicates which alarm conditions currently exist for converter n. Refer to Chapter
6 - Converter (Port 11) Faults and Alarms (Frame 8 and Larger) for information on
these alarm codes.
755 (8+)
755 (8+)
755 (8+)
Options
Reserved BFuseHarness Reserved Reserved Reserved Reserved Reserved Reserved Line Fuse L3 Line Fuse L2 Line Fuse L1 LFuseHarness CT Harness DC Bus Short DC Bus Open Firmware Flt Comm Loss Power Supply Brd NTCShort Brd NTC Open Brd OvrTemp HS NTC Short HS NTC Open Ground Fault Overcurrent Single Phase Line Freq Line Dip HS OvrTemp SCR OvrTemp Precharge Fault Q Full
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
0 = False
1 = True
755 (8+)
755 (8+)
755 (8+)
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Line Loss AC Line High Command Stop BFuse Neg BFuse Pos
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
0 = False
1 = True
755 (8+)
755 (8+)
755 (8+)
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Single Phase Line Freq Minimum Line Line Dip Reserved TVSS Blown HS OvrTemp SCR OvrTemp Reserved Reserved Reserved Reserved Reserved Reserved Phase LossL3 Phase LossL2 Phase LossL1 Precharge
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
0 = False
1 = True
