Allen-Bradley PowerFlex 750 Series Programming Manual

214 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 4 Port 10 and Port 11 Parameters
Inverter n (Port 10)
Parameters
Inverter n parameters apply only to PowerFlex 755 Frame 8 and larger drives.
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
INVERTER N
Status
105
205
305
I1 Fault Status
I2 Fault Status
I3 Fault Status
Inverter n Fault Status
RO 32-bit
Integer
Indicates which fault conditions currently exist for inverter n. Refer to Chapter
6 - Inverter (Port 10) Faults and Alarms (Frame 8 and Larger) for information on these
fault codes.
107
207
307
I1 Alarm Status
I2 Alarm Status
I3 Alarm Status
Inverter n Alarm Status
RO 32-bit
Integer
Indicates which alarm conditions currently exist for inverter n. Refer to Chapter 6 - Inverter (Port 10) Faults and Alarms (Frame 8 and Larger) for information on
these alarm codes.
755 (8+)
755 (8+)
755 (8+)
Options
Reserved Reserved WBrd Fault VBrd Fault UBrd Fault Incompat PS DC Bus Imbal Incomp Brdn Incomp WBrd Incomp VBrd Incomp UBrd NTC Open PSBrdOvrTemp PLI OvrTemp CT Harness SysPSOverCur Sys PS Low IPwrIF PSLow Main PS Low HS OvrTemp IGBT OvrTemp Ground Fault Bus Overvolt Overcur WNeg Overcur WPos Overcur VNeg Overcur VPos Overcur UNeg Overcur UPos ThermalConst Comm Loss Fault Q Full
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
0 = No Fault
1 = Fault
755 (8+)
755 (8+)
755 (8+)
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved HSFan Slow HSFan PS Low Cur Offset W Cur Offset V Cur Offset U Reserved HS OvrTemp IGBT OvrTemp DC Bus Imbal InFan2 Slow InFan1 Slow Sys PS Low Reserved
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
0 = No Alarm
1 = Alarm
