42 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 2 Parameter Organization
How Option Module
Parameters are Organized
Option module parameters are only available when that option is installed in a
host drive. To view and edit option module parameters, select the port number of
the device you want to access from the Status Screen.
11-Series I/O Modules
Parameter descriptions begin on page 242.
File Group Parameters
11-Series I/O
Host Groups
Digital Inputs Dig In Sts 1 Dig In Filt Mask 2 Dig In Filt 3
Digital Outputs Dig Out Sts 5
Dig Out Invert 6
Dig Out Setpoint 7
RO0 Sel 10
RO0 Level Sel 11
RO0 Level 12
RO0 Level CmpSts 13
RO0 On Time 14
RO0 Off Time 15
RO1 Sel 20
TO0 Sel 20
RO1 Level Sel 21
TO0 Level Sel 21
RO1 Level 22
TO0 Level 22
RO1 Level CmpSts 23
TO0 Level CmpSts 23
RO1 On Time 24
TO0 On Time 24
RO1 Off Time 25
TO0 Off Time 25
TO1 Sel 30
TO1 Level Sel 31
TO1 Level 32
TO1 Level CmpSts 33
TO1 On Time 34
TO1 Off Time 35
Motor PTC ATEX Sts 41
Analog Inputs Anlg In Type 45
Anlg In Sqrt 46
Anlg In Loss Sts 47
Anlg In0 Value 50
Anlg In0 Hi 51
Anlg In0 Lo 52
Anlg In0 LssActn 53
Anlg In0 Raw Val 54
Anlg In0 Filt Gn 55
Anlg In0 Filt BW 56
Analog Outpts Anlg Out Type 70
Anlg Out Abs 71
Anlg Out0 Sel 75
Anlg Out0 Stpt 76
Anlg Out0 Data 77
Anlg Out0 DataHi 78
Anlg Out0 DataLo 79
Anlg Out0 Hi 80
Anlg Out0 Lo 81
Anlg Out0 Val 82
Predictive Main PredMaint Sts 99 RO0 Load Type 100
RO0 Load Amps 101
RO0 TotalLife 102
RO0 ElapsedLife 103
RO0 RemainLife 104
RO0 LifeEvntLvl 105
RO0 LifeEvntActn 106
RO1 Load Type 110
RO1 Load Amps 111
RO1 TotalLife 112
RO1 ElapsedLife 113
RO1 RemainLife 114
RO1 LifeEvntLvl 115
RO1 LifeEvntActn 116
