Allen-Bradley PowerFlex 750 Series Programming Manual

230 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 5 Embedded Feature and Option Module Parameters
Embedded EtherNet/IP (Port
13) Parameters
For complete information on the Embedded EtherNet/IP feature, refer to the
PowerFlex 755 Drive Embedded EtherNet/IP Adapter user manual, publication
750COM-UM001
.
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
Embedded EtherNet/IP
1
Thru
16
DL From Net 01
DL From Net 16
Datalinks From Network 01…16
Sets the port number and parameter number to which the selected Datalink connects.
Each selected port/parameter is written with data received from the network (outputs
from the controller).
Parameters 1…14 can only link to floating point parameters.
Parameters 15 and 16 can only link to DINT parameters.
If setting the value manually, the parameter value = (10000 x port number) +
(destination parameter number). For example, to use P1 [DL From Net 01] to write to
Parameter 1 of an optional encoder module plugged into drive Port 5. The value for P1
[DL From Net 01] must be 50001 [(10000 x 5) + 1].
Default:
Min/Max:
0
0 / 159999
RW 32-bit
Integer
17
Thru
32
DL To Net 01
DL To Net 16
Datalinks To Network 01…16
Sets the port number and parameter number to which the selected Datalink connects.
Each selected port/parameter is read and their values are transmitted over the network
to the controller (inputs to the controller).
Parameters 17…30 can only link to floating point parameters.
Parameters 31 and 32 can only link to DINT parameters.
If setting the value manually, the parameter value = (10000 x port number) +
(origination parameter number). For example, to use P17 [DL To Net 01] to read
Parameter 01 of an optional I/O module plugged into drive Port 4. The value for P17 [DL
To Net 01] must be 40001 [(10000 x 4) + 1].
Default:
Min/Max:
0
0 / 159999
RW 32-bit
Integer
33 Port Number
Port number
Displays the drive port to which the embedded EtherNet/IP adapter is dedicated. This is
always Port 13.
Default:
Value:
13
13 / 15
RO 32-bit
Integer
34 DLs From Net Act
Datalinks From Network Actual
Displays the number of actual controller-to- drive Datalinks that the drive is using based
on the I/O connection opened by the controller.
Default:
Min/Max:
0
0 / 16
RO 32-bit
Integer
35 DLs To Net Act
Datalinks To Network Actual
Displays the number of actual drive-to- controller Datalinks that the controller is using
based on the I/O connection opened by the controller.
Default:
Min/Max:
0
0 / 16
RO 32-bit
Integer
36 BOOTP
Bootstrap Protocol
Configures the adapter to use BOOTP so that you can set its IP address, subnet mask, and
gateway address with a BOOTP server. When this parameter is disabled, you must use
the adapter parameters to set these addressing functions. This parameter is only
functional when the IP address switches are set to 001…254 or 888. Power cycle or
reset is required for change to take affect.
Default:
Options:
1 = “Enabled”
0 = “Disabled”
1 = “Enabled”
RW 32-bit
Integer
37 Net Addr Src
Network Address Source
Displays the source from which the adapter node address, subnet mask, and gateway
are taken. This will be switches, Parameters 38…41 [IP Addr Cfg n], or BOOTP. It is
determined by the settings of the octet switches on the adapter. See
Establishing A
Connection With EtherNet/IP on page 17 for details.
Default:
Options:
0 = “Switches”
0 = “Switches”
1 = “Parameters”
2 = “BOOTP”
RO 32-bit
Integer
755
755
755
755
755
755
755
755
755
