Allen-Bradley PowerFlex 750 Series Programming Manual

22 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 2 Parameter Organization
How Drive Parameters are
Organized
DriveExecutive™ programming software displays parameters in “Linear List” or
“File Group Parameter” format. Viewing the parameters in “File Group
Parameter” format simplifies programming by grouping parameters that are used
for similar functions. There are eleven files. Each file is divided into multiple
groups of parameters.
Drive (Port 0) parameter descriptions begin on page 47
.
Basic Parameter View (Port 0)
Parameter 301 [Access Level] set to option 0 “Basic.”
File Group Parameters
Monitor Metering Output Frequency 1
Commanded SpdRef 2
Mtr Vel Fdbk 3
Commanded Trq 4
Torque Cur Fdbk 5
Flux Cur Fdbk 6
Output Current 7
Output Voltage 8
Output Power 9
DC Bus Volts 11
Drive Data Rated Volts 20 Rated Amps 21 Rated kW 22
Motor Control Motor Data Motor NP Volts 25
Motor NP Amps 26
Motor NP Hertz 27
Motor NP RPM 28
Mtr NP Pwr Units 29
Motor NP Power 30
Motor Poles 31
Mtr Ctrl Options Motor Ctrl Mode 35
Maximum Voltage 36
Maximum Freq 37 PWM Frequency 38 IPM Stc OfsTst K
(1)
1660
(1)
Frames 1…7 Only
Volts per Hertz VHz Curve 65
Autotune Autotune 70
Autotune Torque 71
IPM_Lg_25_pct 1630
IPM_Lg_50_pct 1631
IPM_Lg_75_pct 1632
IPM_Lg_100_pct 1633
IPM_Lg_125_pct 1634
IPM_Ld_0_pct 1635
IPM_Ld_100_pct 1636
Feedback & I/O Digin Functions Digital In Cfg 150
DI Enable 155
DI Clear Fault 156
DI Aux Fault 157
DI Stop 158
DI Cur Lmt Stop 159
DI Coast Stop 160
DI Start 161
DI Fwd Reverse 162
DI Run 163
DI Run Forward 164
DI Run Reverse 165
DI Jog 1 166
DI Jog 1 Forward 167
DI Jog 1 Reverse 168
DI Jog 2 169
DI Jog 2 Forward 170
DI Jog 2 Reverse 171
DI Manual Ctrl 172
DI Speed Sel 0 173
DI Speed Sel 1 174
DI Speed Sel 2 175
DI HOA Start 176
DI Accel 2 179
DI Decel 2 180
Control Board IO
755
Digital In Sts 220
Digital Inputs
753
Digital In Sts 220 Dig In Filt Mask 222 Dig In Filt 223
Digital Outputs
753
Dig Out Sts 225
Dig Out Invert 226
RO0 Sel 230
RO0 Level Sel 231
RO0 Level 232
RO0 Level CmpSts 233
TO0 Sel 240
TO0 Level Sel 241
TO0 Level 242
TO0 Level CmpSts 243
Motor PTC
753
PTC Cfg 250 PTC Status 251
Analog Inputs
753
Anlg In Type 255 Anlg In0 Value 260 Anlg In0 Hi 261 Anlg In0 Lo 262
Analog Outputs
753
Anlg Out Type 270
Anlg Out0 Sel 275
Anlg Out0 Data 277
Anlg Out0 DataHi 278
Anlg Out0 DataLo 279
Anlg Out0 Hi 280
Anlg Out0 Lo 281
Anlg Out0 Val 282
Drive Cfg Preferences Speed Units 300 Access Level 301 Language 302
Control Cfg Voltage Class 305 Duty Rating 306 Direction Mode 308 SpdTrqPsn Mode A 309
Auto Manual Ctrl Logic Mask 324
Auto Mask 325
Manual Cmd Mask 326
Manual Ref Mask 327
Alt Man Ref Sel 328
Alt Man Ref AnHi 329
Alt Man Ref AnLo 330
Manual Preload 331
Braking Features Stop Mode A 370
Stop Mode B 371
Bus Reg Mode A 372
Bus Reg Mode B 373
DB Resistor Type 382
DB Ext Ohms 383
DB Ext Watts 384
DB ExtPulseWatts 385
Stop Dwell Time 392
Dec Inhibit Actn 409
Monitor
Motor Control
Feedback and IO
Drive Cong
