242 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 5 Embedded Feature and Option Module Parameters
11-Series I/O Module
Parameters
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
11-Series I/O
Digital Inputs
1Dig In Sts
Digital Input Status
RO 16-bit
Integer
Status of the digital inputs.
2Dig In Filt Mask
Digital Input Filter Mask
RW 16-bit
Integer
Filters the selected digital input.
Important: Only used by 11-Series I/O Module models 20-750-1133C-1R2T and 20-750-1132C-2R. (Modules with 24V DC inputs.)
3Dig In Filt
Digital Input Filter
Sets the amount of filtering on the digital inputs.
Important: Only used by 11-Series I/O Module models 20-750-1133C-1R2T and 20-
750-1132C-2R. (Modules with 24V DC inputs.)
Units:
Default:
Min/Max:
mS
4
2 / 10
RW 32-bit
Integer
Options
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Input 2
Input 1
Input 0
Default0000000000000000
Bit 1514131211109876543210
0 = Input Not Activated
1 = Input Activated
Options
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Input 2
Input 1
Input 0
Default0000000000111111
Bit 1514131211109876543210
0 = Input Not Filtered
1 = Input Filtered
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
11-Series I/O
Digital Outputs
5Dig Out Sts
Digital Output Status
RO 16-bit
Integer
Status of the digital outputs.
(1) Bit 1 = “Trans Out 0” for 11-Series I/O Module model 20-750-1133C-1R2T
= “Relay Out 1” for 11-Series I/O Module models 20-750-1132C-2R and 20-750-1132D-2R
(2) Bit 2 is only used by 11-Series I/O Module 20-750-1133C-1R2T
Options
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Trans Out 1
(2)
Trans Out 0
(1)
Relay Out 0
Default0000000000000000
Bit 1514131211109876543210
0 = Output De-energized
1 = Output Energized
