Allen-Bradley PowerFlex 750 Series Programming Manual

20 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 2 Parameter Organization
About Parameters
To configure a drive module to operate in a specific way, certain drive parameters
may have to be configured appropriately. Three types of parameters exist:
•Numeric Parameters
These parameters have a single numeric value (such as 1750.0 RPM).
•ENUM Parameters
These parameters allow a selection from 2 or more items. The LCD HIM
displays a text message for each item.
•Indirect Parameters
These parameters, represented by a maximum value of 159999 or
159999.15, are used to create assignments or to select either a data source
or destination. The first two digits are used to select a port. The next four
digits select a parameter number. If applicable, the two digits following the
decimal point select a bit. For example, to assign an I/O option module in
port 4 using a run contact on digital input 0, parameter 163 [DI Run] is set
to 040001.00.
•Bit Parameters
These parameters have individual bits associated with features or
conditions. If the bit is 0, the feature is off or the condition is false. If the
bit is 1, the feature is on or the condition is true.
Tab le 3
shows how each parameter type is presented in this manual.
Table 3 - Table Explanation
➊➋ ➌
No. Display Name
Full Name
Description
Values
Read-Write Data Type
MOTOR CONTROL
Motor Data
28 Motor NP RPM
Motor Nameplate Revolutions Per Minute
Rated RPM shown on the motor nameplate.
Units:
Default:
Min/Max:
RPM
1750.0
1.0 / 40000.0
RW Real
Vector Regulator
107 Trq Adapt En
Torque Adaption Enable
Enables or disables the adaptive torque calculation. This selection is active only in motor
control mode flux vector induction (P35 [Motor Ctrl Mode] = 3 “Induction FV”).
Default:
Options:
1 = “Enabled”
0 = “Disabled”
1 = “Enabled”
RW 32-bit
Integer
FEEDBACK & I/O
Digin Functions
164 DI Run Forward
Digital Input Run Forward
Assigns a digital input used to run the drive (2 wire control) and command forward
direction.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
Digital Inputs
220 Digital In Sts
Digital Input Status
RO 16-bit
Integer
Status of the digital inputs resident on the main control board (Port 0).
753
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Digital In 2 Digital In 1 Digital In 0
Default0000000000000000
Bit 1514131211109876543210
0 = Condition False
1 = Condition True
