15-4 Messaging Examples
The DF1 Remote/Local Pass-Thru bit (S2:34/6) is cleared in order to send
messages to the channel 1 DH-485 network as remote DH-485 packets. This
is the default setting for this bit. The DF1 Remote/Local Pass-Thru bit
(S2:34/6) is needed when non-remote capable devices exist on the channel 1
DH-485 network, such as SLC 500 Fixed, SLC 5/01, SLC 5/02, ControlLogix,
FlexLogix, and CompactLogix controllers. The DF1 Remote/Local Pass-Thru
bit (S2:34/6) should be set for passthru messaging to these controllers.
RSLogix500 V 6.10.10 and earlier do not reference S2:34/6 in structured
display formats. In order to alter this bit, change the RADIX from structured
to binary.
TIP
No programming logic is necessary in the passthru
processor.

Allen-Bradley SLC 500 Series Specifications

General

Programming Software	RSLogix 500
Series	SLC 500
Category	Controller
Manufacturer	Allen-Bradley (Rockwell Automation)
I/O Capacity	Up to 4096 I/O points
Communication Ports	DH-485
Programming Languages	Ladder Logic
Operating Temperature	0 to 60 °C (32 to 140 °F)
Relative Humidity	5% to 95% (non-condensing)
Memory	4K to 64K words (depending on the processor)
Power Supply	AC or DC (depending on the module)
