Allen-Bradley SLC 500 Series User Manual

Publication 1747-RM001G-EN-P - November 2008
Troubleshooting Faults 16-5
0012 The ladder program has a memory
error.
• Either noise,
• lightning,
• improper grounding,
• lack of surge suppression on
outputs with inductive loads,
or
• poor power source.
Correct the problem, reload the
program, and run. If the error persists,
be sure to use current RSI
programming software to develop
and load the program.
0013 •The required memory module is
absent, or
•S:1/10 or S:1/11 is not set as
required by the program.
• Either one of the status bits is
set in the program but the
required memory module is
absent, or
• status bit S:1/10 or S:1/11 is
not set in the program stored
in the memory module, but it
is set in the program in the
processor memory.
• Either install a memory
module in the processor, or
• upload the program from the
processor to the memory
module.
0014 Internal file error. • Either noise,
• lightning,
• improper grounding,
• lack of surge suppression on
outputs with inductive loads,
or
• poor power source.
Correct the problem, reload the
program, and run. If the error persists,
be sure to use current RSI
programming software to develop
and load the program.
0015 Configuration file error. • Either noise,
• lightning,
• improper grounding,
• lack of surge suppression on
outputs with inductive loads,
or
• poor power source.
Correct the problem, reload the
program, and run. If the error persists,
be sure to use current RSI
programming software to develop
and load the program.
0016 Startup protection after power loss.
Error condition exists at powerup
when bit S:1/9 is set and powerdown
occurred while running.
Status bit S:1/9 has been set by the
user program.
• Either reset bit S:1/9 if this is
consistent with the
application requirements, and
change the mode back to run,
or
• clear S:1/13, the major fault
bit, before the end of the first
program scan is reached.
0017 NVRAM/memory module user
program mismatch.
Bit S:2/9 is set and the memory
module user program does not match
the NVRAM user program.
Transfer the memory module program
to NVRAM then change to Run mode.
Table 16.2 Going-to-Run Errors (Continued)
Error Code
(Hex)
Description Probable Cause Recommended Action

Allen-Bradley SLC 500 Series Specifications

General

Programming Software	RSLogix 500
Series	SLC 500
Category	Controller
Manufacturer	Allen-Bradley (Rockwell Automation)
I/O Capacity	Up to 4096 I/O points
Communication Ports	DH-485
Programming Languages	Ladder Logic
Operating Temperature	0 to 60 °C (32 to 140 °F)
Relative Humidity	5% to 95% (non-condensing)
Memory	4K to 64K words (depending on the processor)
Power Supply	AC or DC (depending on the module)
