APRILIA TUONO V4 R 2010 User Manual

(*) = clockwise
(**) = anticlockwise
NOTE
TO CHECK FOR FRONT FORK FAILURE, MEASURE THE DIFFERENCE BETWEEN THE BEGIN-
NING OF THE WHEEL HUB AND THE END OF THE FORK SLEEVE
Removing the fork legs
•
Remove the front wheel.
•
Support the fork stanchion and loosen
the screws on the upper yoke.
•
Loosen the lower yoke screws.
•
Remove the stanchion.
See also
Removing the
front wheel
Draining oil
NOTE
THE OPERATIONS DESCRIBED BELOW ARE VALID FOR BOTH STEMS.
Suspensions TUONO V4 R
SUSP - 368
