Rear
REAR WHEEL
pos.
Description Type Quantity Torque Notes
1 Rear wheel spindle nut M25x1.5 1 120 Nm (88.5 lbf ft) -
2 Screws fastening sprocket on
sprocket mount
M10 5 50 Nm (36.88 lbf ft) -
Removing the rear wheel
•
Place the vehicle on its rear service
stand.
•
Loosen and remove the nut on the
wheel axle.
•
Retrieve the thrust washer and the left
hand chain tensioner slider.
Suspensions TUONO V4 R
SUSP - 384
