Disconnect the three connectors.
•
Remove the windshield.
Side body panels
•
Remove the saddle and the passenger
saddle.
•
The operations described below are
valid for both side fairings.
•
Undo and remove the three screws
and remove the fairings.
See also
Seat
Side fairings
The following procedure is relative to a single fair-
ing, but is applicable to both.
•
Remove the two front rivets (1).
Bodywork TUONO V4 R
BODYW - 454
