FAIRING
pos.
Description Type Quantity Torque Notes
1 Screws fastening the lower fairing to
the lower bracket
M5 2 3 Nm (2.21 lbf ft) -
2 Screws fixing the side fairings to the
side spacers
M5 2 1.5 Nm (1.10 lbf ft) -
Seat
•
Remove the passenger saddle.
•
Turn the key clockwise.
Bodywork TUONO V4 R
BODYW - 450
