REAR CHASSIS
pos.
Description Type Quantity Torque Notes
1 Saddle mounting fixing screws M10 4 50 Nm (36.88 lbf ft) -
2 Screws fastening oil radiator mount-
ing bracket to engine
M6 2 8 Nm (5.9 lbf ft) -
3 Passenger saddle and saddle cover
catch plate fixing screws
M6 2 8 Nm (5.9 lbf ft) -
Swinging arm
TUONO V4 R Chassis
CHAS - 399
