Lower cowl
•
Disconnect the two exhaust butterfly
valve control cables
•
Unscrew and remove the two valve ac-
tuator motor screws
•
Remove the valve actuator motor to-
gether with the heat shield.
Engine oil cooler
Chassis TUONO V4 R
CHAS - 416
