Remove the spring paying attention to
drain the oil correctly.
•
Drain the oil into a container of suitable
capacity to collect fluids.
DO NOT DISPOSE OF OIL INTO THE ENVIRONMENT.
DISPOSE OF ENGINE OIL IN A SEALED CONTAINER AND
TAKE IT TO YOUR SUPPLIER OR TO THE NEAREST USED
OIL COLLECTION CENTRE.
Disassembling the fork
•
Discharge the fork, remove the internal
dipstick of the pumping member pin (1)
and the washer (2).
•
Operate repeatedly on the pumping
member pin (3) so as to drain com-
pletely the oil from inside.
•
Slide off the dust scraper from the
sleeve using a screwdriver as a lever.
•
During this operation, pay attention not
to damage the sleeve rim.
TUONO V4 R Suspensions
SUSP - 371
