2.11.1 Compatible Devices
Table 5: Standby Load Battery Size in Ah
Standby Load Battery Size Chart Capacity
Required for
24 H
Capacity
Required for
48 H
Capacity
Required for
60 H
Capacity
Required for
72 H
Capacity
Required for
80 H
Grand Total Standby Current
100 mA to 200 mA 5.8 11.5 14.4 17.3 19.2
201 mA to 300 mA 8.6 17. 3 21.6 25.9 28.8
301 mA to 400 mA 11.5 23.0 28.8 34.6 38.4
401mA to 500 mA 14. 4 28.8 36.0 X X
501 mA to 600 mA 17.3 34.6 X X X
601 mA to 700 mA 20.2 X X X X
701 mA to 800 mA 23.0XXXX
801 mA to 900 mA 25.9 X X X X
901 mA to 1000 mA 28.8XXXX
1001 mA to 1100 mA 31.7 X X X X
1101 mA to 1200 mA 34.6XXXX
Alarm Load Battery Size Chart Capacity
Required for
5 Min
Capacity
Required for
10 Min
Capacity
Required for
15 Min
Capacity
Required for
30 Min
Capacity
Required for
45 Min
Grand Total Standby Current
250 mA to 500 mA 0.1 0.1 0.2 0.3 0.5
501 mA to 999 mA 0.1 0.2 0.3 0.6 0.9
1.0 A to 1.5 A 0.2 0.3 0.5 0.9 1.4
1.6 A to 2.0 A 0.2 0.4 0.6 1.2 1.8
2.1 A to 2.5 A 0.3 0.5 0.8 1.5 2.3
2.6 A to 3.0 A 0.3 0.6 0.9 1.8 2.7
3.1 A to 3.5 A 0.4 0.7 1.1 2.1 3.2
3.6 A to 4.0 A 0.4 0.8 1.2 2.4 3.6
4.1 A to 4.5 A 0.5 0.9 1.4 2.7 4.1
4.6 A to 5.0 A 0.5 1.5 1.5 3 4.5
5.1 A to 5.5 A 0.6 1.1 1.7 3.3 5
Table 6: Compatible Devices
Device Description
D7014 Class “A” Zone
Converter
Converts a Class “B”, Style B initiating circuit on the control panel to a Class “A”, Style D circuit for
connection to field wiring. This module connects to one of the control panel's conventional inputs.
D7015 Class “A” NAC
Converter
Converts a reversing Class “B” NAC to a Class “A” circuit. Compatible with any Class “B”, Style Y
NAC that uses a 2.21 kΩ EOL resistor. When used on a Class “B”, Style Y NAC, it implements a
Class “A”, Style Z NAC. This connects to NAC output on the control panel.
D7030 Eight-Point LED
Annunciator
Identifies the location of a fire alarm for up to eight zones, and up to eight are allowed for each sys-
tem.
D7030X Eight Point LED
Annunciator
Identifies the location of a fire alarm for up to eight zones, and up to eight are allowed for each sys-
tem.
D7030X-S2 Eight Point
LED Annunciator
An eight-zone LED annunciator, of which two zones are reserved for supervisory functions. It has
Power and Trouble LEDs plus eight zone LEDs that can be individually labeled.
