D7024 | Operation and Installation Guide | 6.0 Programming
Bosch | 7/05 | 31499J 33
6.4 Programming Menu Tree
Figure 18: Programming Menu Tree
Level 1
(Main Menu)
Level 2 Level 3 Level 4 Level 5
PROG/0
CMND/#
TEST
HISTORY
DISABLE
DRILL
1- PROG TIME
1- SYSTEM
2 - AUTO TEST
3 - DAYLIGHT SAV
1- TEST TIME
2- TEST FREQ
1- DISABLE
2- ENABLE
2 - SECURITY
1- PINS
2- AUTHORITY
1- PROGRAMR
2- USERS
4 - PROG INPUTS
1- POINT NUMBER
2 - POINT
FUNCTION
3 - POINT COPY
0 - CONFIGURE
1 - LOCAL ONLY
2 - (reserved)
3 - SILENCEABLE
4 -LOOP RESPONSE
5 - (Reserved)
<DRILL> NEXT FCT
<HIST> PREV FCT
1 - FIRE
2 - WATERFLOW
3 - SUPERVISORY
4 - MONITOR
5 - RESET
6 - SILENCE
1- COPY FROM POINT ___
2 - COPY TO FIRST POINT ___
3 - COPY TO LAST POINT ___
0 - FUNCTION
1 - ALARM/TROUBLE
2 - OUTPUT ZONE
3 - VERIFICATION
4 - LATCHING
5 - DESCRIPTION
<DRILL> NEXT PNT
<HIST> PREV PNT
3- PROG SYSTEM
1- (Reserved)
2 - TIMERS
3 - AC LINE SYNC
4 - OPTION BUS
5 - PIN REQUIRED?
6 - (Reserved)
7 - REMOTE PGM
1- SMOKE RESET
2 - AC FAIL DELAY
3 - AUTO SILENCE
4 - (Reserved)
5 - DISPLAY RATE
1- UPDATE BUS
2- SETUP KEYPAD
1- LOCAL
2- REMOTE
To Next Page
