D7024 | Operation and Installation Guide | 7.0 Control Panel Programming
Bosch | 7/05 | 31499J 43
Point Description
Shortcut:
0-PROG > 4-PROG INPUTS > 1-POINT NUMBER
For this feature, the numeric keys are used to enter
alphanumeric information to identify each input
(initiating circuit). The system allows one 16-character
description for each input.
1. Enter the point number you want to program and
press [#].
The display scrolls through the PROG INPUT
options.
2. Press [5] to select DESCRIPTION and access:
3. Enter the description using the numeric,
[SILENCE], and [HISTORY] keys.
4. Press [#] to save the description.
7.4.2 Point Function
Shortcut:
0-PROG > 4-PROG INPUTS > 2-POINT
FUNCTION
There are 16 point functions, each with programmable
features for configuration (such as fire, waterflow, and so
on), local only operation, silencing, and loop response.
The following window appears:
1. Enter the function number you want to program
and press [#] to access:
2. Enter the function you want to program.
Configure
Shortcut:
0-PROG > 4-PROG INPUTS > 2-POINT
FUNCTION
1. Enter the point number you want to program and
press [#].
The display scrolls through the PROG
FUNCTION options.
2. Press [0] to select CONFIGURE and access:
3. Press the number key corresponding to your
selection.
The current setting appears in parentheses on the
first line. Then the preceding window appears.
PNT DSCRPTN ZZZ:
__________________
POINT FUNC.(_ _ _)
(01-16):_ _ _
0- CONFIGURE
1- LOCAL ONLY
2- (reserved)
3- SILENCABLE
4- LOOP RESPONS
5- (reserved)
PROG FUNCT
<DRILL>NEXTPNT
<HIST>PREV PNT
Table 20: Configure Options
Option When activated:
Fire Point shows FIRE ALARM on the control
panel and keypads, a Fire Alarm Report, if
programmed. Fire points are forced to a
latching characteristic when first configured.
Waterflow Point shows WATERFLOW ALARM on the
control panel and keypads, activates
selected output devices, and sends a Water-
flow Alarm Report, if programmed. Waterflow
points are forced to a non-verify characteris-
tic when first configured.
Supervisory Point shows SUPERVISORY ALARM on the
control panel and keypads and sends a
Supervisory Alarm Report, if programmed.
Supervisory points are forced to a non-verify
characteristic when first configured.
Monitor Point shows MONITOR ALARM on the con-
trol panel and keypads, activates selected
output devices, and sends a Fire Alarm
Report, if programmed. When using the SIA
format for communication to the central sta-
tion, a UA Alarm is sent instead of an FA
Alarm.
Reset Point initiates a panel-reset operation to clear
alarms and reset smoke detectors. Only
Points 1 to 8 can be configured as reset
points.
Silence Point initiates a control panel silence opera-
tion to turn off sounders if the control panel is
configured to allow silencing. Only Points 1
to 8 can be configured as silence points.
1- FIRE
2- WATERFLOW
3- SUPERVISORY
4- MONITOR
5- RESET
6- SILENCE
ACTVTN TYPE (_ _)
