D7024 | Operation and Installation Guide | 7.0 Control Panel Programming
54 Bosch | 7/05 | 31499J
7.7.3 BFSK Report Codes
When BFSK reporting is used, most reporting codes are
fixed and do not require programming. The control
panel can send the following reports (Ta b l e 2 9 ) that are
programmed, non-standard BFSK codes.
Press the number key corresponding to your report
code selection. A window allowing you to entry two
hexadecimal digits appears.
7.7.4 SIA Silent Report
When using SIA reporting, all reporting codes but one
are fixed and do not require programming (the SIA
Silent Report is not a standard SIA Code).
All data is entered has hexadecimal values. Enter the
required ASCII value using hexadecimal numbers, one
for the left character or byte and one for the right
character or byte. Use the factory default KB = 0 x 4B,
0 x 42 (refer to the Standard Table of ASCII Values).
1. Press [1] to select the left byte, enter the digits, and
press [#].
2. Enter the right byte the same way you enter the left
byte.
7.8 History Defaults
Shortcut:
0-PROG > 8-HSTRY DEFLTS
The following window appears:
7. 8 .1 C l e a r H i s t o r y
Shortcut:
0-PROG > 8-HSTRY DEFLTS > 1- CLEAR
HISTORY
You can clear some or all History records in the system
using this menu item. The following window appears:
Enter the number of History records you want to delete,
and press [#]. The preceding menu appears.
7.8.2 Default EE
Shortcut:
0-PROG > 8-HSTRY DEFLTS > 2- DEFAULT EE
Use this option to set the control panel to its original
factory-programming configuration. You are prompted
to press [#] to complete the operation, or you can press
[*/CLEAR] to not complete the default.
Table 29: BFSK Reports
Report Description
Off-normal at
Te s t
Sent when the control panel is off-normal at
the Automatic Test time.
Open Reset
Report
Sent when you press [RESET].
Silence Sent when you press [SILENCE].
Fire Drill, Fire
Drill Restore
Sent for fire drill operations.
BFSK RPT CDS
1- OFF NORM TEST
2- OPEN/RESET
3- SILENCE
4- FIRE DRILL
5- FR DRIL RSTR
SIA SIL RPT
1- LEFT BYTE
2- RIGHT BYTE
LEFT BYTE (____)
0 THRU 9
<HISTORY> A
<TEST> B
<DISABLE> C
<DRILL> D
<SILENCE> E
<RESET> F
PROG DEFAULTS
1- CLEAR HSTRY
2- DEFAULT EE
3- ALT 4/2 CDES
4- (reserved)
HIST ITEMS=____
DEL OLDEST 000
