D7024 | Operation and Installation Guide | 7.0 Control Panel Programming
Bosch | 7/05 | 31499J 53
4. Press the number key corresponding to your
selection.
A window allowing you to enter hexadecimal digits
appears. The heading depends on the item you
previously selected:
5. Enter the digit to be reported for the selected
condition by pressing a number key or a special
keys if a hexadecimal character is needed.
6. Press [#] to access and the preceding display.
7.7.2 4/2 Report Codes
4/2 Report codes apply to system conditions only when
you select the 3/1 or 4/2 format. You can program two
digits sent for each condition. Ta b l e 2 8 identifies the
reports you can program.
1. Press [9] to allow you to program additional reports
2. Press [9] to return to the preceding group of
reporting codes.
3. Press the number key corresponding to your code
selection.
4. A window allowing you to enter two hexadecimal
digits appears. The heading depends on the item
you previously selected:
5. Enter the digits you want reported for the selected
condition by pressing a number key or one of the
special keys if a hexadecimal character is needed.
6. Press [#] to access the preceding display.
Table 28: 4/2 Reports
Report Description
System in Test, System in
Test Restore
Sent for Walt Test operations.
Silence Sent when you press
[SILENCE].
Fire Drill, Fire Drill
Restore
Sent for fire drill operations.
Open Reset Report Sent when you press [RESET].
Low Battery, Low Battery
Restore, AC Failure, AC
Failure Restore
Sent for power problems.
Test Report Sent for manual or automatic
Communicator Tests.
Off-normal at Test Sent if the control panel is off-
normal at the Automatic Test
time.
Phone Trouble, Restore Sent for telephone line prob-
lems.
System Trouble, Restore Sent for general system prob-
lems.
FIRE ALARM D1 ( )
0 THRU 9
<HISTORY>: A
<TEST>: B
<DISABLE>: C
<DRILL>: D
<SILENCE>: E
<RESET>: F
4/2 RPT CODS
0- SYSTM IN TST
1- SYS TEST RST
2- SILENCE
3- FIRE DRILL
4- FIRE DRL RST
5- OPEN RST RPT
6- LOW BATTERY
7- LOW BATT RST
8- AC FAILURE
9- MORE
4/2 RPT CODS
0- AC FAIL RST
1- TEST REPORT
2- OFF NORM TEST
3- PHONE 1 TRBL
4- PN 1 TRB RST
5- PHONE 2 TRBL
6- PN 2 TRB RST
7- SYSTEM TROUB
8- SYS TRB RST
SYSTM IN TST ( )
0 THRU 9
<HISTORY>: A
<TEST>: B
<DISABLE>: C
<DRILL>: D
<SILENCE>: E
<RESET>: F
