Account Numbers
Shortcut:
0-PROG > 6-PROG ACC'NTS > 1-PHONE NUMS
The account numbers identify the control panel when it
reports to the central station.
The display scrolls through the Phone Number options.
1. Press [3] for ACCOUNT NUMS and access:
The existing number appears on the top line.
2. Enter the new number on the second line and press
[#].
The preceding window appears. The hexadecimal
digits A through F can be entered by pressing
[TEST] followed by [1] for A, [2] for B, [3] for C, [4]
for D, [5] for E, and [6] for F.
Ton e
Shortcut:
0-PROG > 6-PROG ACC'NTS, > 1-PHONE NUMS
The tone and frequency programming items modify the
reporting format when 3/1 or 4/2 tone burst reporting is
selected as the format. Three parameters are selected
with one setting; the data tone frequency, the
acknowledge tone frequency, and the data rate. The
frequency the control panel uses to send data pulses can
be set for 1900 Hz (19D) or 1800 Hz (18D). The
receiver’s acknowledge tone frequency the control panel
responds to can be set to 1400 Hz (14A) or 2300 Hz
(23A). The rate at which the data pulses are sent can be
set from 10, 20, or 40 pulses per second (10 PPS, 20
PPS, or 40PPS).
The display scrolls through the Phone Number options
(refer to Section 7.6.1 Phone Numbers on page 48).
1. Press [4] for TONE to access:
2. Press the number key corresponding to your
selection.
The preceding window appears.
7.6.2 Phone Control
Shortcut:
0-PROG > 6-PROG ACC'NTS > 2-PHONE
CONTROL
In addition to features associated with each telephone
number, there are features associated with each
telephone line.
Press the number key corresponding to your selection.
For example, Line #1. Line #1 and Line #2 have the
same options. The following window appears:
Refer to Monitor Line and Dialing Type for phone
control options.
Monitor Line
Shortcut:
0-PROG > 6-PROG ACC'NTS, > -PHONE
CONTROL
The telephone line monitor feature supervising the
telephone line to the control panel connection can be
disabled for each telephone line.
1. Select Line 1 or Line 2.
The display scrolls through the Phone Control
options.
2. Press [1] for MONITOR LINE and to access:
3. Press [1] for YES or [2] for NO.
The preceding window appears.
ACCOUNT #1: 0000
NEW NUMBER: 0000
FREQ (_ _)
1- 19D,14A,10PS
2- 18D,23A,10PS
3- 19D,14A,20PS
4- 18D,23A,20PS
5- 19D,14A,40PS
6- 18D,23A,40PS
PHONE CONTROL
1- LINE #1
2- LINE #2
PHONE CONTROL #1
1- MONITOR LINE
2- DIALING TYPE
MONITOR LINE #1
_ _ _ _:YES(1)NO(0)
